The Ford Transit Connect curb-to-curb turning radius is between 18.1 and 20.0 feet as specified in our data below, organized by trim, option package, and model year.
For example the 2018 Ford Transit Connect with the Passenger Van Titanium trim package curb-to-curb turning radius is 18.1 feet.
Check out the Turning Radius specifications for other makes and models.
2023 Ford Transit Connect Turning Radius
Depending on trim, the 2023 Ford Transit Connect curb-to-curb turning radius is between 19.1 and 20.0 feet.
2023 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2023 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2023 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
2023 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2023 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2023 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
2022 Ford Transit Connect Turning Radius
Depending on trim, the 2022 Ford Transit Connect curb-to-curb turning radius is between 19.1 and 20.0 feet.
2022 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2022 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2022 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2022 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2022 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2022 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2021 Ford Transit Connect Turning Radius
The 2021 Ford Transit Connect curb-to-curb turning radius is 20.0 feet.
2021 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI W/98A | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI W/98A | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.5L | I4 | IVCT | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2021 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI W/98A | FWD |
20.0 ft |
40.0 ft |
2021 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI W/98A | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI W/98A | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.5L | I4 | IVCT | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2021 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI W/98A | FWD |
6.1 m |
12.2 m |
2020 Ford Transit Connect Turning Radius
Depending on trim, the 2020 Ford Transit Connect curb-to-curb turning radius is between 19.1 and 20.0 feet.
2020 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2020 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Titanium SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2020 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2020 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van Titanium Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Passenger Van XLT Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
2020 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2020 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Titanium SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2020 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2020 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van Titanium Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Passenger Van XLT Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
2019 Ford Transit Connect Turning Radius
Depending on trim, the 2019 Ford Transit Connect curb-to-curb turning radius is between 19.1 and 20.0 feet.
2019 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2019 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Titanium SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2019 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| XLT SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| XLT SWB w/ Rear Symmetrical Doors Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
2019 Ford Transit Connect Turning Radius (Imperial) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van Titanium Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
| Passenger Van XLT Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
19.1 ft |
38.3 ft |
2019 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XL LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT LWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2019 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT SWB w/ Rear Liftgate Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Van |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Titanium LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Titanium SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XL LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XL LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2019 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| XLT LWB w/ Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT LWB w/ Rear Symmetrical Doors Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| XLT SWB w/ Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| XLT SWB w/ Rear Symmetrical Doors Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Ext Pass Van Titanium Rear Liftgate Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
2019 Ford Transit Connect Turning Radius (Metric) Continued
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van XLT Wagon |
2.0L | I4 | GDI | 8 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van Titanium Rear Liftgate Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
| Passenger Van XLT Wagon |
1.5L | ECOBLUE TC DI | 8 Spd Selectshift Auto | FWD |
5.8 m |
11.7 m |
2018 Ford Transit Connects2018 Ford Transit Connect Turning Radius
Depending on trim, the 2018 Ford Transit Connect curb-to-curb turning radius is between 18.1 and 20.0 feet.
2018 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
2018 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
2017 Ford Transit Connect Turning Radius
Depending on trim, the 2017 Ford Transit Connect curb-to-curb turning radius is between 18.1 and 20.0 feet.
2017 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
2017 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
2016 Ford Transit Connect Turning Radius
Depending on trim, the 2016 Ford Transit Connect curb-to-curb turning radius is between 18.1 and 20.0 feet.
2016 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
2016 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
2015 Ford Transit Connect Turning Radius
Depending on trim, the 2015 Ford Transit Connect curb-to-curb turning radius is between 18.1 and 20.0 feet.
2015 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
2015 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
2014 Ford Transit Connect Turning Radius
Depending on trim, the 2014 Ford Transit Connect curb-to-curb turning radius is between 18.1 and 20.0 feet.
2014 Ford Transit Connect Turning Radius (Imperial)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Imp.) |
Turning Diameter Curb-to-Curb (Imp.) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
20.0 ft |
40.0 ft |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
18.1 ft |
36.1 ft |
2014 Ford Transit Connect Turning Radius (Metric)
| Trim |
Engine | Transmission | Drivetrain |
Turning Radius Curb-to-Curb (Metric) |
Turning Diameter Curb-to-Curb (Metric) |
| Extended Passenger Van Titanium Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XL Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Extended Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
6.1 m |
12.2 m |
| Passenger Van XLT Wagon |
2.5L | I4 | DURATEC | 6 Spd Selectshift Auto | FWD |
5.5 m |
11.0 m |
Ford Transit Connect
Popular Turning Radius Specs
