Ford Freestar Tire Size (2004 - 2007): Your Comprehensive Guide

Researched By The AutoPadre Research Team


The Ford Freestar tire sizes are P235/60R16 or P225/60R16 as specified in our data below, organized by trim, option package, and model yearas specified in our data below, organized by trim, option package, and model year.

Some examples of Ford Freestar tire sizes include the 2004 Ford Freestar Limited Trim with P235/60R16 tires and the 2004 Freestar S Trim with P225/60R16 tires.

Tire Codes Explained (Ex. P255/55VR17)

P - Denotes the tires intended use. (P = Passenger, LT = Light Truck, T = Temporary, ST = Special Trailer)

255 - Width of the tire tread in millimeters.

55 - Tire Profile. The ratio between the profile (sidewall) height and the width of the tire's tread. It is measured in percent. A lower number is a low profile tire and a higher number has a higher sidewall.

V - Speed Rating. ( ie. U = 125 mph, H = 130 mph, V = 149 mph ... etc)

R - Tire Construction. (R = Radial, B = Bias Belt, D = Diagonal)

17 - Rim (wheel) diameter in inches.

Check out the Tire And Rim Sizes specifications for other makes and models.

Jump To Model Year

2007 Ford Freestar Tire Sizes

The 2007 Ford Freestar tire sizes are P235/60R16 and P225/60R16.

2007 Ford Freestar Tire Sizes
Trim Engine | Transmission | Drivetrain Front Tire Size | Rear Tire Size
SEL Wagon 4.2L | V6 | OHV | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
SE Wagon 4.2L | V6 | OHV | 4 Spd Auto w/OD | FWD P225/60R16 | P225/60R16
Limited Wagon 4.2L | V6 | OHV | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16

2006 Ford Freestar Tire Sizes

The 2006 Ford Freestar tire sizes are P235/60R16 and P225/60R16.

2006 Ford Freestar Tire Sizes
Trim Engine | Transmission | Drivetrain Front Tire Size | Rear Tire Size
SEL Wagon 4.2L | V6 | OHV | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
SE Wagon 3.9L | V6 | OHV | 4 Spd Auto w/OD | FWD P225/60R16 | P225/60R16
Limited Wagon 4.2L | V6 | OHV | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16

2005 Ford Freestar Tire Sizes

The 2005 Ford Freestar tire sizes are P235/60R16 and P225/60R16.

2005 Ford Freestar Tire Sizes
Trim Engine | Transmission | Drivetrain Front Tire Size | Rear Tire Size
SES Wagon 3.9L | V6 | SPI | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
SEL Wagon 4.2L | V6 | SPI | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
SE Wagon 3.9L | V6 | SPI | 4 Spd Auto w/OD | FWD P225/60R16 | P225/60R16
S Wagon 3.9L | V6 | SPI | 4 Spd Auto w/OD | FWD P225/60R16 | P225/60R16
Limited Wagon 4.2L | V6 | SPI | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16

2004 Ford Freestar Tire Sizes

The 2004 Ford Freestar tire sizes are P235/60R16 and P225/60R16.

2004 Ford Freestar Tire Sizes
Trim Engine | Transmission | Drivetrain Front Tire Size | Rear Tire Size
SES Wagon 3.9L | V6 | SPI | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
SEL Wagon 4.2L | V6 | SPI | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
SE Wagon 3.9L | V6 | SPI | 4 Spd Auto w/OD | FWD P225/60R16 | P225/60R16
S Wagon 3.9L | V6 | SPI | 4 Spd Auto w/OD | FWD P225/60R16 | P225/60R16
Limited Wagon 4.2L | V6 | SPI | 4 Spd Auto w/OD | FWD P235/60R16 | P235/60R16
