Scion xB Battery Sizes (2004 - 2015): Battery Replacement Guide

Researched By The AutoPadre Research Team


The Scion xB battery sizes are: 24F (model years 2008 to 2015), 34R (model years 2008 to 2009), or 25 (model years 2004 to 2006) as specified in our data below, organized by trim, option package, and model year.

“As an Amazon Associate we earn a commission from qualifying purchases clicked through on this page.”
Scion xB Battery Size(s)
Year Trim Battery Size Code Battery Size (L X W X H) Inches Get Here (paid link)
2015 L4/2.4L 24F 10 3/4" x 6 13/16" x 9" Amazon
2014 L4/2.4L 24F 10 3/4" x 6 13/16" x 9" Amazon
2013 L4/2.4L 24F 10 3/4" x 6 13/16" x 9" Amazon
2012 L4/2.4L 24F 10 3/4" x 6 13/16" x 9" Amazon
2011 L4/2.4L 24F 10 3/4" x 6 13/16" x 9" Amazon
2010 L4/2.4L 24F 10 3/4" x 6 13/16" x 9" Amazon
2009 Standard (2) 34R 10 1/4" x 6 13/16" x 7 7/8" Amazon
2009 (1) Standard (2) 24F 10 3/4" x 6 13/16" x 9" Amazon
2008 Standard (2) 34R 10 1/4" x 6 13/16" x 7 7/8" Amazon
2008 (1) Standard (2) 24F 10 3/4" x 6 13/16" x 9" Amazon
2006 Standard 25 9 1/16" x 6 7/8" x 8 7/8" Amazon
2005 Standard 25 9 1/16" x 6 7/8" x 8 7/8" Amazon
2004 Standard 25 9 1/16" x 6 7/8" x 8 7/8" Amazon

(1) The Battery Council International (BCI) uses battery group codes consisting of letters and numbers (ie. H6, T4, 24, 34r). These refer to the battery size that will best fit (physical dimensions, terminal locations and type) a specific vehicle.

Check out the Battery Size specifications for other makes and models.

Jump To Model Year

2015 Scion xB Battery Size

The recommended 2015 Scion xB battery size is 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2015 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
L4/2.4L 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2014 Scion xB Battery Size

The recommended 2014 Scion xB battery size is 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2014 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
L4/2.4L 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2013 Scion xB Battery Size

The recommended 2013 Scion xB battery size is 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2013 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
L4/2.4L 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2012 Scion xB Battery Size

The recommended 2012 Scion xB battery size is 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2012 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
L4/2.4L 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2011 Scion xB Battery Size

The recommended 2011 Scion xB battery size is 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2011 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
L4/2.4L 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2010 Scion xB Battery Size

The recommended 2010 Scion xB battery size is 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2010 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
L4/2.4L 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2009 Scion xB Battery Size

The recommended 2009 Scion xB battery sizes are 34R (Height: 10 1/4" x Width: 6 13/16" x Length: 7 7/8") or 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2009 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
Standard (2) 34R 10 1/4" x 6 13/16" x 7 7/8" 26.0 cm x 17.3 cm x 20.0 cm
(1) Standard (2) 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2008 Scion xB Battery Size

The recommended 2008 Scion xB battery sizes are 34R (Height: 10 1/4" x Width: 6 13/16" x Length: 7 7/8") or 24F (Height: 10 3/4" x Width: 6 13/16" x Length: 9").

2008 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
Standard (2) 34R 10 1/4" x 6 13/16" x 7 7/8" 26.0 cm x 17.3 cm x 20.0 cm
(1) Standard (2) 24F 10 3/4" x 6 13/16" x 9" 30.6 cm x 17.3 cm x 22.9 cm

2006 Scion xB Battery Size

The recommended 2006 Scion xB battery size is 25 (Height: 9 1/16" x Width: 6 7/8" x Length: 8 7/8").

2006 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
Standard 25 9 1/16" x 6 7/8" x 8 7/8" 23.0 cm x 17.5 cm x 22.5 cm

2005 Scion xB Battery Size

The recommended 2005 Scion xB battery size is 25 (Height: 9 1/16" x Width: 6 7/8" x Length: 8 7/8").

2005 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
Standard 25 9 1/16" x 6 7/8" x 8 7/8" 23.0 cm x 17.5 cm x 22.5 cm

2004 Scion xB Battery Size

The recommended 2004 Scion xB battery size is 25 (Height: 9 1/16" x Width: 6 7/8" x Length: 8 7/8").

2004 Scion xB Battery Size(s)
Trim Battery Size Code Battery Size (L X W X H) (Imp.) Battery Size (L X W X H) (Metric)
Standard 25 9 1/16" x 6 7/8" x 8 7/8" 23.0 cm x 17.5 cm x 22.5 cm
