Volvo V90 Towing Capacity Overview
The Volvo V90 towing capacity ranges between 1,650 lbs. and 3,700 lbs as specified in our data below, organized by trim, option package, and model year.
For instance, the 2020 Volvo V90 has a minimum towing capacity of 1,650 lbs, while the 2018 Volvo V90 has a maximum towing capacity of 3,700 lbs.
Factors such as trim level, engine configuration, and drivetrain can impact the towing capacity of a specific model year of Volvo V90.
Check out the Towing Capacity specifications for other makes and models.
All towing capacities are braked capacities. This means that the trailer being towed has a
braking system installed to assist with the vehicle's own braking. The towing capacities for trailers without
brakes will be much less.
Confirm all towing capacities with the owner's manual.
2024 Volvo V90 Towing Capacity Data
The 2024 Volvo V90 towing capacity is 3,500 lbs. regardless of its trim level or drivetrain.
2024 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country Ultimate B6 Hybrid |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | AWD | 295 HP | 310 ft/lbs |
3,500 lbs |
| Cross Country Plus B6 Hybrid |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | AWD | 295 HP | 310 ft/lbs |
3,500 lbs |
2023 Volvo V90 Towing Capacity Data
The 2023 Volvo V90 towing capacity is 3,500 lbs. regardless of its trim level or drivetrain.
2023 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country Ultimate B6 Wagon |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | AWD | 295 HP | 310 ft/lbs |
3,500 lbs |
| Cross Country Plus B6 Wagon |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | AWD | 295 HP | 310 ft/lbs |
3,500 lbs |
2022 Volvo V90 Towing Capacity Data
The 2022 Volvo V90 towing capacity is 3,500 lbs. regardless of its trim level or drivetrain.
2022 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country Base B6 Wagon |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | AWD | 295 HP | 310 ft/lbs |
3,500 lbs |
2021 Volvo V90 Towing Capacity Data
The 2021 Volvo V90 towing capacity is between 2,000 lbs. and 3,500 lbs as shown in the table below.
2021 Volvo V90 Towing Capacities
| Trim |
Engine | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country T6 Wagon |
2.0L | Superchraged | I4 | 16V TURBO W/POLESTAR | AWD | 330 HP | 325 ft/lbs |
3,500 lbs |
| T6 RDesign Wagon |
2.0L | Superchraged | I4 | 16V TURBO W/POLESTAR | AWD | 330 HP | 325 ft/lbs |
3,500 lbs |
| T6 Inscription Wagon |
2.0L | Superchraged | I4 | 16V TURBO W/POLESTAR | AWD | 330 HP | 325 ft/lbs |
3,500 lbs |
| T5 RDesign Wagon |
2.0L | Turbocharged | I4 | 16v w/polestar | FWD | 258 HP | 295 ft/lbs |
2,000 lbs |
| T5 Inscription Wagon |
2.0L | Turbocharged | I4 | 16v w/polestar | FWD | 258 HP | 295 ft/lbs |
2,000 lbs |
2020 Volvo V90 Towing Capacity Data
The 2020 Volvo V90 towing capacity is 1,650 lbs. regardless of its trim level or drivetrain.
2020 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country T6 Wagon |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T6 RDesign Wagon |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T6 Inscription Wagon |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T5 RDesign Wagon |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
| T5 Inscription Wagon |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
| Cross Country T6 |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
2020 Volvo V90 Towing Capacities Continued
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| T6 RDesign |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T5 RDesign |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
| T6 Inscription |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T5 Inscription |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
2019 Volvo V90 Towing Capacity Data
The 2019 Volvo V90 towing capacity is 1,650 lbs. regardless of its trim level or drivetrain.
2019 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country T6 Ocean Race Wagon |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| Cross Country T6 Wagon |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| Cross Country T5 Wagon |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | AWD | 250 HP | 258 ft/lbs |
1,650 lbs |
| T6 RDesign Wagon |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T6 Inscription Wagon |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T5 RDesignTurbo Wagon |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
2019 Volvo V90 Towing Capacities Continued
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| T5 Inscription Wagon |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
| Cross Country T6 Volvo Ocean Race |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| Cross Country T6 |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| Cross Country T5 |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | AWD | 250 HP | 258 ft/lbs |
1,650 lbs |
| T6 RDesign |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T5 RDesign |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
2019 Volvo V90 Towing Capacities Continued
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| T6 Inscription |
2.0L | Superchraged | I4 | 16V TURBO | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
1,650 lbs |
| T5 Inscription |
2.0L | Turbocharged | I4 | 16v | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
1,650 lbs |
2018 Volvo V90 Towing Capacity Data
The 2018 Volvo V90 towing capacity is between 3,500 lbs. and 3,700 lbs as shown in the table below.
2018 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country T6 Ocean Race Wagon |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
3,500 lbs |
| Cross Country T6 Wagon |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
3,500 lbs |
| Cross Country T5 Wagon |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | AWD | 250 HP | 258 ft/lbs |
3,500 lbs |
| T6 RDesign Wagon |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
3,700 lbs |
| T6 Inscription Wagon |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
3,700 lbs |
| T5 RDesignTurbo Wagon |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
3,700 lbs |
2018 Volvo V90 Towing Capacities Continued
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| T5 Inscription Wagon |
2.0L | Intercooled Turbo | I4 | 8 Spd Auto w/OD | FWD | 250 HP | 258 ft/lbs |
3,700 lbs |
2017 Volvo V90 Towing Capacity Data
The 2017 Volvo V90 towing capacity is 3,500 lbs. regardless of its trim level or drivetrain.
2017 Volvo V90 Towing Capacities
| Trim |
Engine | Transmission | Drivetrain | Horsepower | Torque |
Towing Capacity |
| Cross Country T6 Wagon |
2.0L | Turbo | I4 | 8 Spd Auto w/OD | AWD | 316 HP | 295 ft/lbs |
3,500 lbs |
- a fishing boat and trailer usually weighs between 900 lbs. to 6,000 lbs.
- a tent trailer typically weighs between 1,000 lbs. to 1,500 lbs.
- a fifth-wheel travel trailer averages between 12,000 lbs. to 15,000 lbs.
